| 型 号 |
频率范围
(MHz) |
增益
CW(dB) |
输出功率
(W) |
增益平坦度
(dB) |
输入驻波比 |
电源电压
(V) |
电流
(A) |
连接形式 |
外形尺寸
长×宽×高
(mm) |
| UIYPA210120B |
0.1~10 |
55 |
300 |
±1.0 |
1.5 |
+48 |
12 |
SMA to N |
210×120×31 |
| UIYPA450504A |
0.1~30 |
60 |
1000 |
±1.5 |
1.5 |
+220 |
15 |
SMA |
450×504×138 |
| UIYPA200100A |
0.1~40 |
50 |
120 |
±1.5 |
1.5 |
+28 |
10 |
SMA to N |
200×100×35 |
| UIYPA15080A |
1~30 |
47 |
60 |
±1.0 |
1.5 |
+24 |
4.5 |
SMA |
150×80×25 |
| UIYPA210120A |
1~30 |
53 |
220 |
±1.0 |
1.5 |
+28 |
14 |
SMA to N |
210×120×31 |
| UIYPA10050A |
1~1000 |
26 |
1 |
±2.0 |
2.0 |
+12 |
0.1 |
SMA |
100×50×20 |
| UIYPA200100B |
20~512 |
53 |
120 |
±1.5 |
1.5 |
+28 |
9 |
SMA to N |
200×100×25 |
| UIYPA15080C |
20~1000 |
40 |
5 |
±2.0 |
1.5 |
+12 |
3 |
SMA |
150×80×22 |
| UIYPA16885A |
20~1000 |
50 |
60 |
±2.0 |
1.5 |
+28 |
5 |
SMA |
168×85×21 |
| UIYPA14075A |
25~512 |
50 |
60 |
±1.5 |
1.5 |
+28 |
6 |
SMA |
140×75×21.5 |
| UIYPA150120A |
30~512 |
45 |
15 |
±1.5 |
1.5 |
+14.4 |
2.5 |
MCX |
150×120×20 |
| UIYPA15080B |
30~1000 |
45 |
12 |
±1.5 |
1.5 |
+13.8 |
3 |
SMA |
150×80×22 |
| UIYPA10075A |
400~480 |
38 |
50 |
±1.0 |
1.5 |
+12 |
4 |
SMA |
100×75×20 |
| UIYPA23688A |
700~860 |
50 |
100 |
±1.0 |
2.0 |
+28 |
7.5 |
SMA to N |
236×88×27 |
| UIYPA23688B |
800~1000 |
50 |
120 |
±1.0 |
1.5 |
+28 |
7.5 |
SMA to N |
236×88×27 |
| UIYPA23688C |
860~960 |
50 |
100 |
±1.0 |
2.0 |
+28 |
7.5 |
SMA to N |
236×88×27 |
| UIYPA20390A |
900~1300 |
50 |
100 |
±0.5 |
1.5 |
+28 |
|
N |
203×90×27 |
| UIYPA200100C |
2200~2700 |
50 |
60 |
±1.5 |
1.5 |
+28 |
7.5 |
SMA to N |
200×100×25 |
|
