| 型 号 |
带通频率
(MHz) |
插损
(dB) |
隔离度
（dB) |
输入
驻波比 |
输出
驻波比 |
通过功率
（W） |
反射功率
（W） |
连接形式 |
温度
(°C) |
尺寸
长x宽x高(mm) |
UIY8PD144103A |
0.4~4.0 |
4.5 |
18 |
1.5 |
1.4 |
10 |
3 |
SMA-F |
-35~+65 |
144.5×103.5×15.5 |
UIY8PD10880A |
0.5~2.0 |
1.5 |
20 |
1.4 |
1.2 |
30 |
3 |
SMA-F |
-55~+85 |
108×80×10 |
UIY8PD10875A |
0.8~2.5 |
1.3 |
20 |
1.4 |
1.3 |
30 |
3 |
SMA-F |
-55~+85 |
108×75×10 |
UIY8PD10863A |
1.0~2.0 |
1.0 |
20 |
1.3 |
1.3 |
30 |
3 |
SMA-F |
-55~+85 |
108×63×10 |
UIY8PD10863B |
1.0~4.0 |
1.5 |
20 |
1.4 |
1.3 |
30 |
3 |
SMA-F |
-55~+85 |
108×63×10 |
UIY8PD10863C |
2.0~4.0 |
0.8 |
20 |
1.3 |
1.3 |
30 |
3 |
SMA-F |
-55~+85 |
108×63×10 |
UIY8PD10863D |
2.0~8.0 |
1.8 |
18 |
1.6 |
1.4 |
30 |
3 |
SMA-F |
-55~+85 |
108×63×10 |
UIY8PD10863E |
4.0~8.0 |
1.2 |
18 |
1.5 |
1.4 |
30 |
3 |
SMA-F |
-55~+85 |
56×43×10 |
UIY8PD10162A |
4.0~18.0 |
1.8 |
15 |
2.0 |
1.8 |
30 |
3 |
SMA-F |
-55~+85 |
101.5×62×10 |
|
